AT-19 |
Secondary Sources |
Notes |
| Primary Source |
|
16
|
|
|
| No of Crew |
|
3 |
|
|
| Engine: |
|
|
|
|
| Qty |
|
1 |
|
|
| Model |
|
R-680-13
|
|
|
|
Displacement |
(cu
in) |
680.4
|
|
|
| Power |
|
|
|
|
|
Military |
(HP) |
|
|
|
|
War Emergency |
(HP) |
|
|
|
| Normal |
(HP) |
280 |
|
|
| Take Off |
(HP) |
295
|
|
|
| Eng Dims |
|
|
|
|
|
Length |
(ft) |
3.13 |
|
|
|
Width/Dia |
(ft) |
3.63 |
|
|
|
Height |
(ft) |
|
|
|
| Base
Engine Wt |
(lb) |
577
|
|
|
| Propeller |
|
|
|
|
| # Blades |
|
2 |
|
|
| Dia |
(ft) |
8.50
|
|
|
|
Manufacturer |
|
Fixed |
|
|
| Type |
|
|
|
|
| Wing |
|
|
|
|
| Span |
(ft) |
41.88 |
|
|
| Root
Thickness |
(%) |
15.9% |
|
|
| |
(in) |
15.25 |
|
|
| Total
Area |
(sq
ft) |
221.6 |
|
|
|
Wing (less Ailerons & Flaps) |
(sq
ft) |
|
|
|
|
Ailerons |
(sq
ft) |
|
|
|
|
Flaps |
(sq
ft) |
|
|
|
| Tail Area |
(sq
ft) |
36.14 |
|
|
| V Tail
Area |
(sq
ft) |
13.64 |
|
|
|
Fin |
(sq
ft) |
6.41 |
|
|
|
Rudder |
(sq
ft) |
7.23 |
|
|
| H Tail
Area |
(sq
ft) |
22.50 |
|
|
|
Stabilizer |
(sq
ft) |
12.53 |
|
|
|
Elevator |
(sq
ft) |
9.97 |
|
|
| Total Control Surf Area |
(sq
ft) |
17.20 |
|
|
| Length |
|
|
|
|
| Overall |
(ft) |
29.50 |
|
|
| Fuselage |
(ft) |
|
|
|
| Body |
(ft) |
|
|
|
|
Body Depth |
(ft) |
5.50 |
|
|
| Body
Width |
(ft) |
4.50 |
|
|
| Fuel Tank Volume |
(gal) |
|
|
|
| Wing
Tanks |
(gal) |
|
|
|
|
FuselageTanks |
(gal) |
|
|
|
| Oil Tank Volume |
(gal) |
|
|
|
| Water Injection Fluid Tank
Volume |
(gal) |
|
|
|
| Wetted Area (sqf) |
(sq
ft) |
|
|
|
| Pwr Ldng |
(lb/HP) |
13.32
|
|
|
| Wing Ldng |
(lb/sq
ft) |
17.73 |
|
|
| Struct. Des. GW |
(lb) |
|
|
|
| Ultimate Load Factor |
(G's) |
|
|
|
| Design Speed |
(mph) |
|
|
|
| Not to Exceed Speed |
(mph) |
|
|
|
| |
|
|
|
|
| Total Struct Weight |
|
1447.2 |
|
|
| Total
Wing |
|
440.5 |
|
|
|
Wing |
|
361.4 |
|
|
|
Ailerons |
|
23.1 |
|
|
|
Flaps |
|
22.1 |
|
|
|
Struts |
|
38.9 |
|
|
|
Fuselage Carry-Through |
|
|
|
|
| Tail |
|
|
|
|
|
H Tail |
|
49.5
|
|
|
|
Stabilizer |
|
32.0 |
|
|
|
Elevator |
|
17.5 |
|
|
|
V Tail |
|
23.6 |
|
|
|
Fin |
|
10.3
|
|
|
|
Rudder |
|
13.3 |
|
|
Wires
|
|
13.0 |
|
|
| Body +
Eng Section + LG |
|
|
|
|
| Body + LG |
|
920.6
|
|
|
| Body |
|
669.6
|
|
|
|
Fuselage |
|
578.3 |
|
|
|
Engine Section |
|
91.3 |
|
|
| Landing
Gear |
|
251.0
|
|
|
|
Mn Landing Gr |
|
223.4
|
|
|
|
Tail/Nose Aux LG |
|
27.6
|
|
|
| Tail Hook |
|
|
|
|
| Booms |
|
|
|
|
| Nacelles |
|
|
|
|
| Total Propulsion Weight |
|
812
|
|
|
| Engine w/ Accessories |
|
591
|
|
|
|
Engine(s) as Installed |
|
557 |
|
|
|
Accessories |
|
34 |
|
|
| Turbocharger(s) |
|
|
|
|
| Controls |
|
6.9 |
|
|
| Propeller(s) |
|
120.9
|
|
|
|
2-Blade |
|
120.9
|
|
|
|
3-Blade |
|
|
|
|
|
4-Blade |
|
|
|
|
| Starting
System |
|
20.7
|
|
|
| Water
Injection System |
|
|
|
|
|
Tanks |
|
|
|
|
|
Piping Etc |
|
|
|
|
| Cooling
System |
|
|
|
|
| Lube System |
|
9.5 |
|
|
|
Tanks |
|
4.9 |
|
|
|
Piping Etc |
|
4.6 |
|
|
| Fuel
System |
|
63.0
|
|
|
|
Tanks |
|
45.4 |
|
|
|
Piping Etc |
|
17.6 |
|
|
| Total Sys. & Eqpmt. |
|
608.3
|
|
|
|
Instruments |
|
46.2
|
|
|
| Surface
Controls |
|
69.6
|
|
|
| Hydraulics |
|
127.0 |
|
|
|
Electrical Equip |
|
159.2
|
|
|
| Electronics (Purple means
incl in Furn/Gray in Useful Ld) |
|
206.3 |
|
|
| Arm Prov/Equipment
& Armor |
|
|
|
|
| Furnishings |
|
|
|
|
| Anti-Ice (If not in Furn) |
|
|
|
|
| Other /Misc |
|
|
|
|
| Hoisting Gear |
|
|
|
|
| Floatation Gear |
|
|
|
|
| Armor Plate |
|
|
|
|
| |
|
|
|
|
| Empty Wt |
|
2867.5
|
|
|
| Basic Mission Useful Load |
|
1062.0
|
|
|
| Crew |
|
600.0 |
|
|
| Equipment |
|
|
|
|
| Oil |
|
38.0 |
|
|
| Fuel |
|
420.0
|
|
|
| Fuel & Oil Trapped
in Systems |
|
|
|
|
| Water Solution for Engine
Injection |
|
|
|
|
| Bombs/Torp Etc |
|
|
|
|
| Radio (if Not Included in
Empty Wt) |
|
|
|
|
| Nav Equipment |
|
|
|
|
| Oxygen System |
|
|
|
|
| Armament |
|
4.0 |
|
|
| Guns &
Ammo |
|
|
|
|
| Guns |
|
|
|
|
| Ammo |
|
|
|
|
| Pyrotechnics |
|
4.0 |
|
|
| Camera |
|
|
|
|
| Other |
|
|
|
|
| Other Useful Load |
|
|
|
|
| Basic Mission GW |
|
3929.5
|
|
|
